SONY XCG-H280E索尼參數協議SONY XCG-H280E-01

SONY XCG-H280E

2/3英寸280萬像素逐行掃描EXview HAD CCD II? CCD（全高清），可見光和近紅外波段的靈敏度比以前的型號高。 除了繼承索尼XCD系列的一些獨特功能，如批量觸發和順序觸發模式，XCG-H280E具有全高清高幀率圖像傳輸功能，具有8,10或12位視頻 數據輸出。

淘寶購買

單擊進入淘寶官方店購買

論壇提問

單擊進入專業論壇注冊提問

分享至：

Sony is expanding its popular XCG GigE camera series with the introduction of a new high-quality, high-sensitivity monochrome camera.


The new XCG-H280E incorporates a 2/3-type EXview HAD CCD II? sensor which provides greater sensitivity in the visible and near-infrared wavelengths than previous models. In addition to inheriting some of the unique features of Sony’s XCD Series such as Bulk Trigger and Sequential Trigger modes, the XCG-H280E features a full-HD high frame rate image-transfer capability with 8-, 10-, or 12-bit video data output.



The XCG-H280E incorporates the GigE Vision? interface standard, based on Gigabit Ethernet technology. In response to the growing demand for large-scale systems, this interface enables the camera to transfer a large amount of data over long distances. The use of an Ethernet cable and the availability of a wide variety of peripheral devices contribute to significant cost-cutting benefits when designing a complete vision system. By utilizing the features and benefits of the GigE Vision, the XCG-H280E camera is ideally suited to the demanding requirements of ITS (Intelligent Transportation Systems) and machine-vision applications.

  • Excellent picture quality thanks to progressive scan CCD technology from Sony CCD read out supports Partial scan, Binning 8/10/12 bits / pixel (Raw data or B/W)
  • Shutter Manual (2 to 1/100,000s)
  • Gain control Manual (0 to + 18dB) /Auto
  • 16 Memory Channels
  • GigE Vision interface based on Gigabit ethernet 1000 BASE-T technology
  • Packet resend mechanism
  • Data transfer length up to 100m
  • Advanced trigger modes (sequence, pulse width, delay)
  • Fixed trigger latency (from hardware input to exposure start)
  • Exposure output, digital inputs/outputs 1,024 Bytes User Memory

GigE Vision Interface
The adoption of the GigE Vision? Version 1.2 adds to the outstanding value and performance of the XCG-H280E camera. Being GenICamcompatible, the XCG-H280E is easy to integrate, thanks to a host of commercially available image-processing libraries.

High Frame Rate Image Transfer
The XCG-H280E features a high readout rate of uncompressed images for smooth and clear results. This also enables the camera to capture fast-moving objects without sacrificing image quality.

High Sensitivity
Utilizing Sony’s latest EXview HAD CCD II technology enables the XCG-H280E to capture clear images in lowlight environments. When used with an infrared strobe, the camera’s high sensitivity in the near-infrared wavelength delivers outstanding picture quality.

Image Buffer
The XCG-H280E is equipped with an image buffer, which serves as temporary storage for captured images for later transmission or retransmission. This function allows users to maximize bandwidth in multiple-camera operations or reconfirm specific images as required.

Bulk Trigger Mode & Sequential Trigger Mode
In addition to conventional Trigger mode, the XCG-H280E camera features advanced Bulk Trigger and Sequential Trigger modes. The camera supports 16 memory channels that can store up to 16 different camera setups (exposure, gain, LUT). Bulk Trigger mode allows the XCG camera to capture up to 16 images in rapid succession using a single software or hardware trigger. Sequential Trigger mode allows the camera to capture a single image using successive setups stored in the memory channels with each software or hardware trigger.

Low Power Consumption and Compact Design
The XCG-H280E camera features low power consumption and a compact 50 x 50 x 57.5 mm (2 x 2 x 2 3/8 in) design. The camera also has the ability to operate at temperatures of up to 50°C / 122°F."
